Canon 5424C002 - CR-X500 Outdoor 4K PTZ Camera with 15x Optical Zoom (White)

1050880

New

If you're working on a field or studio production with a need to shoot outdoors in the...
Read more

Visuals price :

23 400,00 CHF


25 295,40 CHF (tax incl.)

Rectangle
Guarantee: garantie Visuals Guarantee 36 Months
In-house aftersales service: update, repair and backup.

Availability: clock

Usually ships within 2 weeks


Order now and we will deliver as soon as possible,
or please contact us on 022 561 07 07 for other arrangements.

- +

1050880
More info

Outdoor 4K PTZ Camera with 15x Optical Zoom (White)







Specifications



Image sensor


Image Sensor 1-Chip 1" CMOS Sensor
Sensor Resolution Actual: 13.4 Megapixel

Effective: 8.29 Megapixel (3840 x 2160)
Gain 0 to 33 dB
Minimum Illumination 3 Lux at 1/60 Shutter Speed
Camera
Shutter Speed 1/3 to 1/1000 sec
Max Digital Zoom 30x ( in 1080p)
Built-In ND Filter Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters
Lens
Optical Zoom Ratio 15x
Focal Length 8.3 to 124.5mm (35mm Equivalent Focal Length: 25.5 to 382.5mm)
Field of View Horizontal: 5.7 to 73°

Vertical: 3.2 to 45.2°
Maximum Aperture f/2.8 to 4.5
Image Stabilization Optical
Focus Control Autofocus

Manual Focus
Video Output
Broadcast System Compatibility NTSC, PAL
Output Formats SDI: 3840 x 2160p at 59.94 fps

1920 x 1080p at 23.98, 25, 29.97, 50, 59.94 fps

1920 x 1080i at 50, 59.94 fps

1280 x 720p at 50, 59.94 fps

Control


Presets 100
Move Speed Pan: 0.5 to 25°/sec

Tilt: 0.3 to 20°/sec
Movement Range Pan: 340° (-170 to 170°)

Tilt: 80° (-50 to 30°)
Supported Control Protocols NU

RS-422
Interfaces
Video Output Connectors 1 x BNC (3G-SDI) Female
Control Interface 1 x 9-Pin D-Sub (RS-422) Input
Other I/O 1 x BNC (Genlock) Input/Output
Power
PoE Support None
Power Connectors 1 x Proprietary (10 to 15 VDC)
Power Consumption Power Supply: 10.5 to 15 VDC 90 W
Enviromental
Operating Temperature 5 to 104°F / -15 to 40°C
Operating Humidity 10 to 90%
Storage Humidity 0,9
General
IP Rating IP55
Dimensions 15.35 x 15.2 x 13.27" / 38.99 x 38.6 x 33.71 cm (Excluding Protrusions)
Weight 37.5 lb / 17 kg










Accessoires
Cable Video
Cable IT
Video Tripod system
Pedestal
Remote control PTZ
