EIZO CG2700S - Swiss Edition - 27" High-End IPS-LED Panel
The flagship 27-inch monitor marks a new generation of ColorEdge with a new design. With 2K...
Read more
More info
This flagship 27-inch monitor marks a new generation of ColorEdge with a new exterior design. With 2K WQHD (2560 x 1440) resolution, 400 cd/m2 high brightness, and HDR gamma support, the monitor reproduces content in remarkable detail. USB Type-C® connectivity provides a streamlined experience so professionals in video editing, game development, photography, and more can focus on creating.
|
Specifications |
|
| Model Variations | CG2700S-BK | |
| Panel | ||
| Type | IPS | |
| Backlight | Wide-Gamut LED | |
| Size | 27.0" (68.5 cm) | |
| Native Resolution | 2560 x 1440 (16:9 aspect ratio) | |
| Viewable Image Size (H x V) | 596.7 x 335.7 mm | |
| Pixel Pitch | 0.233 x 0.233 mm | |
| Pixel Density | 109 ppi | |
| Display Colors | 1.07 billion colors, 10-bit display (from a palette of 278 trillion, 16-bit LUT) | |
| Viewing Angles (H / V, typical) | 178°, 178° | |
| Brightness (typical) | 400 cd/m2 | |
| Contrast Ratio (typical) | 1600:1 | |
| Response Time (typical) | 19 ms (gray-to-gray) | |
| Color Gamut (typical) | Adobe RGB: 99%, DCI-P3: 98% | |
| Video Signals | ||
| Input Terminals | USB Type-C (DisplayPort Alt Mode, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3) | |
| Digital Scanning Frequency (H / V) | USB Type-C, DisplayPort: 26 - 89 kHz / 23 - 61 Hz HDMI: 15 - 89 kHz / 23 - 61 Hz |
|
| USB | ||
| Upstream | USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 92 W max.), USB 3.1 Gen 1: Type-B | |
| Downstream | USB 3.1 Gen 1: Type-A x 2 USB 2.0: Type-A x 2 |
|
| USB LAN Adapter | RJ-45 (1000BASE-T) | |
| Power | ||
| Power Requirements | AC 100 - 240 V, 50 / 60 Hz | |
| Typical Power Consumption | 17 W | |
| Maximum Power Consumption | 187 W | |
| Power Save Mode | 0.5 W or less | |
| Built-in Calibration Sensor | Yes | |
| Features & Functions | ||
| Brightness Stabilization | Yes | |
| Digital Uniformity Equalizer | Yes | |
| Preset Modes | User, BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, AdobeRGB, sRGB, Calibration (CAL), SYNC_SIGNAL | |
| HDR Gamma | HLG, PQ curve | |
| OSD Languages | English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese | |
| Others | Color Adjustment, PQ Option, HLG Option, SelfCalibration, Input Color Format, YUV Color Matrix, Input Range, I/P Conversion, Picture Expansion, BT.709 Gamut warning, Luminance Warning, Marker, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority, Ethernet | |
| Physical Specifications | ||
| Dimensions (Landscape, W x H x D) | 638 x 415.9 - 570.9 x 245 mm | |
| Dimensions (Without Stand, W x H x D) | 638 x 390 x 86.2 mm | |
| Dimensions (Landscape with Hood, W x H x D) | 657.4 x 425.6 - 580.6 x 353.5 mm | |
| Net Weight | 9.4 kg | |
| Net Weight (Without Stand) | 6.4 kg | |
| Net Weight (With Hood) | 10.1 kg | |
| Height Adjustment Range | 155 mm | |
| Tilt | 35° Up, 5° Down | |
| Swivel | 344° | |
| Pivot | 90° | |
| Hole Spacing (VESA Standard) | 100 x 100 mm | |
| Environmental Requirements | ||
| Operating Temperature | 0 - 35°C | |
| Operating Humidity (R.H., non condensing) | 20 - 80% | |
| Certifications & Standards (Please contact EIZO for the latest information.) | CB, CE, UKCA, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics, TUV/Color Accuracy (Quick Stability), FograCert Softproofing System (class A) | |
| Dedicated Software | ||
| Easy Screen-to-Print Color Matching Tool Quick Color Match | Supported | |
| Proprietary Software | ||
| Color Management Software ColorNavigator 7 | Supported | |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) | ||
| Signal Cables | USB Type-C (2 m), HDMI (2 m) | |
| Others | AC power cord, USB Type-A - USB Type-B cable (2 m), Setup guide, Adjustment certificate, ScreenCleaner, Monitor hood, Warranty card | |
| Warranty | 5 Years 2 5 Zero bright sub-pixels for six months from date of purchase for purchases made on September 1, 2015 or later. |
|
| Dimension Drawing | ||
-
