Epiphan ESP1150 - Pearl-2
The Pearl-2 Base Video Mixer from Epiphan is a powerful live-production mixer that lets you...
Read more
More info
Epiphan ESP1150 - Pearl-2
Epiphan Pearl-2 Overview
The Pearl-2 Base Video Mixer from Epiphan is a powerful live-production mixer that lets you create visually appealing live video programs by combining, encoding, switching, and recording up to six video sources and two audio sources. With Pearl-2 you can share any kind of video, anytime, anywhere. Simple to use with a web-based portal for initial configuration, you get a drag and drop interface to create completely customizable layouts for your live stream. You can choose to keep Pearl-2's default encoding settings or customize them to meet your exact needs. Control the video recorder and video switcher capabilities via the touchscreen or the tablet-friendly Epiphan Live interface.
Key Features
- Reliable, simple live streaming with Pearl-2's integrated live video production workflow
- Works with video sources from SD to 4K (separate add-on required for 4K)
- Connect up to six sources at once to encode and stream one 4K Ultra HD program, or up to six 1080p Full HD programs
- Use any combination of your video sources connected to the HDMI, 4K HDMI, or 12G-SDI video input ports, or from IP cameras over your network
- Sixth generation Intel i7 processor
- Use the touchscreen or Epiphan Live to preview and change the live content in your video programs
- See changes immediately in your live video stream, and on displays connected to Pearl-2’s 4K HDMI video output ports
- Simultaneously send live stream to YouTube, Facebook, and any other CDN or video portal
- At the same time, use the built-in streaming server to stream locally to web browsers, smart TVs, and set-top boxes
- Control your streaming and recording from any mobile device or computer on your local network
- Capture embedded HDMI and SDI audio, or use the XLR/RCA ports for professional level audio from mixing consoles and sound equipment
- Built-in attenuation and gain adjustment
- Design your own custom layouts, including picture-in-picture, by using the drag and drop editor in Pearl-2’s web-based Admin panel
- Combine, crop, and scale up to six video sources
- Customize the video source completely with backgrounds, overlay images, text, and timestamping
- Hold hundreds of hours of HD recordings on the 512GB solid-state hard drive
- Configure automatic file transfer to a networked storage or local USB drive via USB 3.0, to ensure your files are always protected
- Connect your headphones and monitor audio using the front-mounted 3.5mm audio jack and on-screen VU meter
- Send the content to a larger confidence monitor with Pearl-2’s two 4K HDMI video output ports
- Use Pearl-2’s built-in streaming server to share via unicast or multicast stream to up to 50 viewers with popular streaming protocols such as HTTP, HLS, FLV, ASF, UPnP, and SAP
- Publish your live video stream to a large audience using an enterprise streaming server or CDN using RTMP or RTSP
- Supported CDNs including Facebook Live, YouTube, Wowza, Livestream, Akamai, Ustream, and more
- Stream your final program output, in any desired resolution, while also recording high quality ISOs for post-processing
- Pearl-2 integrates easily with content management systems (CMS) and with learning management systems (LMS) such as Blackboard, Kaltura, Mediasite, and Moodle
|
Specifications |
|
Processing |
|
|
| Processing Resolution | DCI 4K | |
Input |
|
|
| Video Input Connectors | 2 x BNC (12G-SDI) 4 x HDMI (DVI / HDMI 1.4a) 1 x RJ45 (HX / NDI) |
|
| Audio Input Connectors | 4 x 3-Pin XLR Stereo Analog Female 1 x 2RCA Stereo Analog Female |
|
Output |
|
|
| Video Output Connectors | 1 x HDMI (HDMI 1.4a) 1 x HDMI (HDMI 2.0) |
|
| Audio Output Connectors | 1 x 1/8" / 3.5 mm TRS Stereo Analog Female | |
| Embedded Audio Output | HDMI | |
Connectivity |
|
|
| HDCP Support | Yes | |
| IP Encoding/Decoding |
|
|
| IP Video | H.264: 4096 x 2160 Encoding |
|
| Internal Recording | ||
| Internal Storage | 512 GB | |
| Display | ||
| Display Size | 4.3" | |
| Screen Resolution | 800 x 480 | |
| Power | ||
| Built-In Battery | None | |
| Power Consumption | Device: 100 to 240 VAC | |
| Environmental | ||
| Operating Temperature | 32 to 104°F / 0 to 40°C | |
| General | ||
| Dimensions | 11.81 x 9.45 x 3.54" / 30 x 24 x 8.99 cm | |
| Weight | 8.4 lb / 3.8 kg | |
| Packaging Info | ||
| Package Weight | 19.8 lb | |
| Box Dimensions (LxWxH) | 19.1 x 15.7 x 7.9" |
-
