Sennheiser TCCM CT-W 2FT - Ceiling Tile
The Ceiling Tile brings versatility and adaptability, elevating your meeting experience...
Read more
More info
Sennheiser TCCM CT-W 2FT - Ceiling Tile specs
| Audio output | 1 x 3-pin terminal (fits Phoenix contact MCVW 1.5-3-ST-3.81), 1x Digital Dante Network Audio (RJ-45) |
| Network/Control | 1 x RJ-45 Ethernet Port for PoE power supply and data/control communication |
| Supply voltage | PoE IEEE 802.3af Class 3 IEEE 802.3at / Typ 2 / Class 4 (when cascaded) |
| Power consumption | Approx. 8 W |
| Safety certification | IEC/EN 62368-1 (including UL 2043 testing and compliance) |
| Dimensions (Ø x H) | 477 x 46 mm (16 x 1.8 ") |
| Weight | max. 4.9 kg (10.8 lbs) |
| Finish | Black |
Acoustic properties
| Transducer principle | Pre-polarized condenser microphone |
| AF frequency response | 100 Hz to 16,000 Hz |
| Sensitivity | 0 dBV/Pa (890 mV/Pa) |
| Signal-to-noise ratio | 79 dB (A) |
| Equivalent noise level | 15 dB (A) |
| Number of KE 10-237 microphone capsules | 15 |
| Pick-up pattern | Beam pattern |
| Max. sound pressure level | 98 dB SPL |
| Dynamic range | 83 dB (A) |
Ambient Conditions
| Temperature Range - Operation | 0 to 40°C |
| Temperature Range - Storage | -10 to 60°C |
| Relative air humidity | 20 to 95%, non-condensing |
Physical & Dimensions
| Height | 45.8mm |
| Length | 590.8mm |
| Width | 590.8mm |
| Weight | 4.1kg |
-
