Telycam TLC-50TC(NDI)-B - V-Joy+, (NDI) PTZ Remote, Black
Telycam TLC-50TC is a full-featured, easy-to-operate PTZ joystick control keyboard, applied...
Read more
More info
|
Specifications |
|
|
| Model | TLC-50TC/TLC-50TC(NDI) | TLC-50TC | |
| Control Ports | NDI|HX, RS232, RS422, RS485 | RJ45, RS232, RS422, RS485 | |
| RJ45 | Ethernet port, POE（IEEE802.3af） | ||
| RS232 | DB9 Male head | ||
| RS422 | 3.81 Spacing terminal, T＋, T－, R＋, R－ | ||
| RS485 | 3.81 Spacing terminal ,T＋, T－ | ||
| Control Protocols | NDI ®|HX, VISCA, VISCA over IP, VISCA TCP, VISCA UDP, ONVIF, PELCO-P, PELCO-D, | VISCA, VISCA over IP, VISCA TCP, VISCA UDP, ONVIF, PELCO-P, PELCO-D, | |
| Upgrade Port | Type-C | ||
| LCD Screen | 3.12-inch OLED screen, blue light, 256×64 pixel | ||
| Working Power | 12V, 1A | ||
| Working Temperature | -10℃~50℃ | ||
| Working Humidity | 20%~80% | ||
| Storage Temperature | -20℃~60℃ | ||
| Storage Humility | 0~90% | ||
| Dimension | 320.5mm×156.5mm×118mm | ||
| Net Weight | 1.05kg | ||
-
