For professionals and enthusiasts alike.
More info
|
Specifications |
|
| Panel | ||
| Display Size | 8” | |
| High Resolution | 1920×1200 | |
| Aspect Ratio | 0,6736111111 | |
| Wide Viewing Angle | 160 Degrees (H) /160 Degrees (V) | |
| Color Depth | 16.7 M | |
| Back Light | LED | |
| Brightness | 290 cd/m2 | |
| Contrast Ratio | 900:1 | |
| INPUT | 2 x BNC SDI 1/2 Channel inputs (Auto-detected and compatible to 3G/HD/SD-SDI) 1 x BNC |
|
| Composite Video input | (Share with SDI 1 input BNC) 1 x HDMI HDMI input (optional) |
|
| OUTPUT | 1 x BNC SDI signal output (3G/HD/SD-SDI Auto-Detected) 1 x HDMI HDMI output(optional) |
|
| COMPANTIBLE SDI FORMATS | ||
| SMPTE-425M-A/B | 4:2:2 YCbCr 10-bit 1080P (60/59.94/60) 4:4:4 YCbCr/RGB 10-bit 1080i (60/59.94/50) 4:4:4 YCbCr/RGB 12-bit 1080p(30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) 4:2:2 YCbCr 12-bit 1080i (60/59.94/50) 1080p(30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) 4:4:4 YCbCr/RGB 10-bit 720P (60/59.94/50/30/29.97/25/24/23.98) |
|
| SMPTE-274M | 1080i (60/59.94/50) 1080P(30/29.97/24/25/23.98/30sF/29.97sF/25sF/24sF/23.98sF) |
|
| SMPTE-296M | 720P (60/59.94/50/30/29.97/25/24/23.98) | |
| SMPTE-260M | 1035i (60/59.94) | |
| SMPTE-125M | 480i (59.94) ITU-R BT.656 576i (50) |
|
| Audio In / Out | SDI/HDMI Audio In 16 Channels SDI/2 Channels HDMI embedded audio |
|
| Audio Meter Display | H/V Audio Level Meter Display (VU+PPM) | |
| Audio Headset Output | 3.5mm Headset Jack | |
| Built-in Speaker | 2.0Wx1 | |
| GENERAL | ||
| Operating Temperature | -10 Degrees Celsius～50 Degrees Celsius | |
| Input Voltage | DC 8.4V 14.8V | |
| Power Consumption | 18 W | |
| Power-Saving Mode | Turn off unimportant Key Automatically if no signal input | |
| Accessory | Power adaptor | |
-
