Angenieux 320850 - EZ2 Pack (S35 + FF) - Meter

The Angénieux Type EZ-2 for FF/VistaVision format is a wide zoom lens with a zoom factor of 2.7x. Its focal range and aperture are set set to 22-60mm F2.8/T3. By exchanging the rear lens group, the lens becomes a 15-40mm F1.9/T2 covering an image circle up to 30mm diagonal.







Main Features







- 22-60mm T3 / f2.8, image coverage up to 46mm diagonal



- Lightweight (2,070g / 4.6 pounds)



- Extremely wide coverage with minimal distortion



- Internal focusing & zooming, lens size remains constant throughout zooming & focusing range.



- Traditional angenieux look, colorimetry matches those of Optimo & OPTIMO STYLE series.



- Short MOD 0.6m / 2 feet



- In-lens thermal compensation, significantly reduces temperature drift.



- Precise and ergonomic focus ring with scale rotation of 300 degrees



- Luminescent FTZ markings, easy reading in dark



- Available with PL lens mount, easy conversion to EF or E mount by users



- Front diameter 114mm, matte boxes compatible with those used on OPTIMO & OPTIMO STYLE compact zooms



- Detachable ENG style zoom grip available from MOVCAM







Field Of View for 37.7×24.9mm





Focal Length





- 22mm



- 60mm





Horizontal angular field of view





- 80.2°



- 35°





Vertical angular field of view





- 57.4°



- 24°





at MOD





- 658 x 426mm



- 245 x 165mm







Specifications





ZOOM RATIO 2.7x

FOCAL LENGTH 22-60 mm

APERTURE f/2.8-T3

CLOSE FOCUS 2ft – 0.6 m

INTERNAL FOCUS Yes

IMAGE COVERAGE Up to 46

WEIGHT (APPROX.) 4.6lb-2.07kg

LENGTH 210 mm

FRONT DIAMETER 114 mm
