Canon 5736C003 - XA-70 4K Camcorder
Mehr Infos
|
Specifications |
|
| Image Sensor | ||
| Image Sensor | 1-Chip 1" CMOS Sensor | |
| Sensor Resolution | Effective: 14.2 Megapixel | |
| Signal-to-Noise Ratio | 50 dB | |
| Minimum Illumination | 0.067 Lux at 1/4 Shutter Speed | |
| Camera | ||
| Shutter Speed | 1/8 to 1/10,000 sec (In 30p/60p Mode) | |
| Max Digital Zoom | 24x ( in 1080p) | |
| Flip / Mirror Support | Image Flip, Mirror (Vertical) | |
| Lens | ||
| Optical Zoom Ratio | 12x | |
| Focal Length | 9.3 to 111.6mm | |
| Field of View | Horizontal: 6.1 to 64.6° | |
| Maximum Aperture | f/2.8 | |
| Minimum Focus Distance | Wide: 3.1" / 8.0 cm Telephoto: 39.4" / 1.0 m |
|
| Image Stabilization | Digital | |
| Focus Control | Autofocus Manual Focus |
|
| Video Output | ||
| Output Formats | HDMI: 3840 x 2160 at 30 fps 1920 x 1080p at 60 fps SDI: 3840 x 2160 at 30 fps 1920 x 1080p at 60 fps RJ45: 3840 x 2160 at 30 fps 1920 x 1080p at 60 fps |
|
| Embedded Audio | HDMI SDI |
|
| Control | ||
| Move Speed | Pan: 0.05 to 100°/sec Tilt: 0.05 to 50°/sec |
|
| Movement Range | Pan: 350° Tilt: 120° (-30 to 90°) |
|
| Tally Light | Yes | |
| Supported Control Protocols | IP IR RS-232 RS-422 RS-485 VISCA |
|
| Interfaces | ||
| Video Output Connectors | 1 x RJ45 (NDI) Female 1 x HDMI Type A Female 2 x BNC (3G-SDI) Female |
|
| Audio I/O | 1 x 1/8" / 3.5 mm Stereo Input 1 x 1/8" / 3.5 mm Stereo Output |
|
| Other I/O | 2 x RJ45 (RS-232, RS-422, RS-485) 1 x USB Type-A (Genlock) 1 x BNC (Genlock) |
|
| Power | ||
| PoE Support | PoE++ 802.3bt | |
| Power Connectors | 1 x Barrel / Coaxial (12 VDC) | |
| Power Consumption | to 22 W | |
| Environmental | ||
| Operating Temperature | 14 to 104°F / -10 to 40°C | |
| Operating Humidity | 0,8 | |
| General | ||
| Dimensions | 9.72 x 7.72 x 6.5" / 247 x 196 x 165 mm | |
| Weight | 7.5 lb / 3.4 kg | |
| Packaging Info | ||
| Package Weight | 10.785 lb | |
| Box Dimensions (LxWxH) | 14.3 x 11.9 x 10.7" | |
