Specifications |
|
| LOS Range | 1,600ft (500m) | |
| Operating Frequency | 1904 – 1919 MHz: China 1880 – 1900 MHz: Europe, South Africa, much of Asia, Hong Kong SAR, Australia, and New Zealand (10 channels) 1880 – 1895 MHz: Taiwan (8 channels) 1893 – 1906 MHz: Japan (J-DECT) 1910 – 1920 MHz: Brazil (10 channels) 1910 – 1930 MHz: Much of Latin America excluding Brazil. 1920 – 1930 MHz: USA & Canada |
|
| Transmit Power | ≤ 21 dBm | |
| Bandwidth | 1.728 MHz | |
| Modulation Mode | GFSK | |
| Frequency Response | 100 Hz – 7 kHz (±3dB) @1 kHz | |
| Receiver Sensitivity | ≤ -90 dBm | |
| SNR | > 55dB | |
| Antenna Gain | 4 dBi (all directions) | |
| DC Voltage Range | 7 – 30V, < 1A@12V | |
| V/G Mount Battery Voltage Range | 11 – 30V, < 1A@12V | |
| Power Consumption | < 1A@12V | |
| Dimensions | 302mm × 181.52mm × 63.6mm | |
| Weight | 1797.5g (63.4oz) | |
| Temperature Range | -10 – 45℃ (working) -20 – 60℃ (storage) |
|
-
